Manufacturer:Emerson
Model Number:MTR-1362-N-D-E-S-MODRR
Motor Type:Stepping Motor
Frame Size:NEMA 34
Shaft Diameter:1 7/8 inches
Voltage Rating:12-24V DC
Phase:4-wire
Rated Torque:3.5Nm @ 2.8A
Step Angle:1.8°
Holding Torque:4.2Nm
Insulation Class:Class B
Weight:5.6 lbs
Certifications:CE, RoHS, UL
This Emerson stepping motor is an excellent choice for applications that require accurate positioning and smooth operation. It comes with a sturdy design suitable for heavy-duty industrial machinery. The motor features a single shaft measuring 1 7/8 inches, providing enhanced stability during operation. With a rated torque of 200 oz-in and voltage/current ratings of 24VDC and 3.0A respectively, it delivers high-performance output under demanding conditions.
The MTR-1362-N-D-E-S-MODRR utilizes a two-phase design with a step angle of 1.8°, ensuring precise movements with minimal vibration. Its phase resistance and inductance values are optimized for efficient energy consumption, while its rotor inertia ensures stable operation at varying speeds.
Built to meet international safety standards, this stepping motor is certified CE and RoHS compliant, making it safe for use in various environments. Its compact yet robust construction makes installation straightforward, and the motor can be easily integrated into existing systems for seamless operation.
